Impact energy: 1J, 2.75J, 5.5J
Energy Accuracy: 1%
Impact speed (m/S): 3.5
Pendulum moment:
Pd1 = 0.53590Nm/ Pd2.75 = 1.47372Nm
Pd5.5 = 2.94744Nm/ Pd11 = 5.8949Nm/ Pd22 = 11.7898Nm
Distance between striking edge to upper surface of clamps: 22mm
Raising angle: 150°
Round angle radius of striking edge: R=0.8mm
Sample span size(mm): 10, 12.7
Impact center distance (mm): 335
Scale Reading:
0-1J Min.scale:0.01J
0-2.75J Min.scale:0.025J
0-5.5J Min.scale:0.05J
Dimension: 550x350x900mm
Weight(Kg): 80kg
