Working temperature range: -30 ... 150 °C
Ambient temperature range: 5 ... 40 °C
Temperature stability: 0.1 ± K
Heater power max.: 16 kW
Max. power consumption: 18 kW
Current consumption: 25 A
Max. discharge pressure: 5.5 bar (50 Hz), 7.0 bar (60 Hz)
Max. pump flow pressure: 60 L/min (50 Hz); 70 L/min (60 Hz)
In / Outlet connection thread (outside): M38 x 1.5
Min. filling volume: 9.7 L
Max. filling volume: 25.5 L
Recommended cooling water temperature: 15 °C
Cooling water flow rate: 29 L/min
Pressure difference cooling water min.: 0.8 bar
Maximal pressure cooling water: 10 bar
Dimensions (WxDxH): 760 x 650 x 1605 mm
Weight: 244 kg
Noise level: 67 dB(A)
Power supply: 400 V; 3/PE; 50 Hz & 460 V; 3/PE; 60 Hz
