Basic Accuracy : R: 0.5%, L: 1.0%, C: 1.0%
Measurement Range (R) : 25mΩ to 10MΩ
Measurement Range (C) : 0.3pF to 500uF
Measurement Range (L) : 1.0uH to 1.0H
Test Frequency : 100Hz – 10kHz
Test Voltage : 0.45Vrms
Over Voltage Protection (between test tips) : No
Resistance (R) : Yes
Capacitance (C) : Yes
Inductance (L) : Yes
Impedance (Z) : No
Dissipation Factor (D) : No
Quality Factor (Q) : No
Phase Angle (Ө) : No
Equivalent Series Resistance (ESR) : Yes
Direct Current Resistance (DCR) : No
Diode Check : No
LED Testing : No
Continuity : No
Sorting : No
Recording : No
Self Calibration : No
PC Connectivity : No
Dimensions (L x W x H) : 151 x 19 x 14.5mm
Weight : 30g
Display : OLED 0.91″, 128 x 32 Resolution
Battery : 3.7V LiPO, 150mAH, Rechargeable
External Power Source : DC 5V, micro-B USB Connector
SMD Test Probe : Gold Plated (Regular)
