Flow range: 0.00011-190 mL/min
Speed accuracy: 0.5%
Speed range: 0.1-50 rpm
Speed resolution: 0.1 rpm
Power supply: AC 220V ± 10%, 50Hz/60Hz (standard); AC 110V ± 10%, 50Hz/60Hz (optional)
Power consumption: < 25W
External logic level control signal: 5V, 12V (standard), 24V (optional). External analog control signal: 0-5V (standard); 0-10V, 4-20mA (optional)
External communication interface: RS485 MODBUS
Ambient temperature: 0-40 °C
Relative humidity: < 80%
IP grade: IP31
Dimensions (L x W x H): 225 x 132 x 128 mm (8.86 x 5.20 x 5.04 inch)
Weight: 2.7 kg (6.0 lbs)
| Drive type | Pump head | Ch | Tubing size (mm) | Flow rate per channel (mL/min) |
| BT50S (304SS case) | DG10-1 (10 rollers) | 1 | Wall:0.8~1, ID:≤3.17 | 0.0001-24.5 |
| DG10-2 (10 rollers) | 2 | Wall:0.8~1, ID:≤3.17 | 0.0001-24.5 | |
| DT10-18 | 2 | Wall:0.8~1, ID:≤3.17 | 0.0002-41 | |
| DT10-28 | 2 | Wall:0.8~1, ID:≤3.17 | 0.0002-41 | |
| YZ15 | 1 | 13# 14# 16# 19# 25# 17# | 0.006-140 | |
| YT15 | 1 | 13# 14# 16# 19# 25# 17#1 8# | 0.006-190 |
