Specifications
Flow range: 400～13000mL/min
Speed range: 30-600 rpm
Speed resolution: 1 rpm
Speed accuracy: 3%
Power supply: AC100-240V, 50/60Hz
Power consumption: < 300W
External logic level control signal: 5V, 12V (standard), 24V (optional)
External analog control signal: 0-5V (standard); 0-10V, 4-20mA (optional)
Communication interface: RS485 MODBUS interface
Operating condition: Temperature 0-40°C; Relative humidity < 80%
IP grade: IP31
Dimensions (L x W x H): 356 x 235 x 225 mm
Weight: 13 kg (28.7 lbs)
| Drive type | Pump head | CH | Tubing size (mm) | Flow rate (L/min) per channel |
| WG600S (304SS) | YZ35 | 1 | 73# 82# | 0.4- 13 |
| 2 x YZ35 | 2 | 73# 82# | 0.4- 13 |
