Leeb LHRS-150 Digital Rockwell hardness tester

Hardness measuring range: HRA 20-80; HRB 20- 100; HRD 40-77; HRF 60-100; HRG 30-94; HRH 80-100; HRK 40-100; HRM 50-115; HRR 50-115

preliminary testing force : 60kgf( 558N) ; 100kgf( 960N); 150kgf ( 1471N)

Testing force: 0.1 HR

Duration time: 0- 60S

Data output : built-in printer, RS232

Max height of specimen; 170mm

Distance of indenter to outer wall; 165mm]

Power supply: AC 220V+ 5%; 50-60Hz

Overall dimension (mm): 520*240*700mm

Net weight: about 80Kg

Standard accessories: Indenter x2; Hardness blocks X3; testing platform *3;

weights X3; power cable X3 : RS232 cable *1; paper of printer X1 ; manual ; certificate; warranty card
