Test force: LHVS-5Z: 0.3Kgf (2.94N)、0.5Kgf(4.9N)、1Kgf (9.8N)、2Kgf (19.6)
LHVS-10Z: 0.3Kgf (2.94N)、0.5Kgf(4.9N)、1Kgf (9.8N)、3Kgf(29.4N)、5Kgf
(49N)、10Kgf (98N)
LHVS-30Z: 1Kgf (9.8N)、3Kgf(29.4N)、5Kgf (49N)、10Kgf (98N)、20Kgf
(196N)、30Kgf (294N)
LHVS-50Z: 1Kgf (9.8N)、5Kgf (49N)、10Kgf (98N)、20Kgf (196N)、30Kgf
(294N)、50Kgf (490N)
Measuring Range: 8-2900HV
Indication of Hardness Value: Large Oled Touch Screen display
Min measuring unit: 0.125µm (with objective lens)
Test microscope magnification: 200X(Measuring)，100X（observation）
Data output Inside Printer
Load control (force applied): Automatic（Loading, Dwell, Unloading）
Max Height of Specimen: 165mm
Distance of Indenter to outer wall : 130mm
Power supply: AC220V+5%，50-60Hz
Net weight: About 45Kg
