Operating Frequency: 0.5MHz～20MHz
Scan Range(mm): 0-10000mm
Velocity Range（m/s）: 100～20000
Vertical linearity error: ≤2%
Dynamic Range: ≥35dB
Horizontal linearity error: ≤0.1%
Testing sensitivity: ≥65dB (Depth 200mm, Φ2 flat bottom hole)
Measuring channel: 500
Storage : 1000
Gain Range(dB): 0~130
Standard Probes: Straight probe: 2.5MHz, diameter 20mm, cable Q9-Q9
Angle probe: 4MHz, 60 degree, 8*9 mm, cable Q9-C5
Dimension: 240×185×55mm
Weight: 1.85kg
Optional Accessories: Optional probes, Cables, Calibration blocks, Coupling agent
