Minimum Size Detection: 0.5 μm
Standard 2 channel sizes: 0.5, 5.0 μm
Optional 4 channel sizes: 0.5, 1.0, 5.0, 10.0 μm
Additional Available sizes: 0.5, 0.7, 1.0, 3.0, 5.0, 7.0, 10.0 μm
Flow Rate / Nozzle Size: 0.1 CFM (2.83 LPM), 1/8” inlet, 1/4” outlet fitting
Concentration Limits: 4,000,000 Particles/ft3@10% (137,200,000/m3)
Data Storage Records: 3,000
Zero Count Level: < 1 Count / 5 minutes (meets specifications of JIS B 9921 and reporting requirements of ISO 21501-4 Annex C)
External Vacuum Requirements: Nominal 1.0 CFM 18" (45.72 cm) of Hg
Self Diagnostics: Laser power supply, laser current, laser power, photo detector power supply, background voltage, photo detector health.
Communication: Ethernet or Serial.
Modbus Protocols: TCP or RTU or ASCII
Software: LMS Pro or LMS Xchange
Calibration: ISO 21501-4 Compliant and Accredited ISO 17025
Power: 24 VDC, PoE
Dimensions: 6.38”x 2.93“ x 4.63” (16.2 x 7.4 x11.7 cm)
Weight: 1.4 lbs (0.63 kg)
Accessories: Smart brackets
