Minimum Size Detection: 0.5 μm
Standard 2 channel sizes: 0.5, 5.0 μm
Optional 4 channel sizes: 0.5, 1.0, 5.0, 10.0 μm
Additional Available sizes: 0.7, 3.0 μm
Flow Rate / Nozzle Size: 0.1 CFM (2.83 LPM), 1/8” inlet
Concentration Limits: 4,000,000 Particles/ft3@10% coincidence loss
Communication: Ethernet or Serial.
Modbus Protocols: TCP or RTU or ASCII
Data Storage Records: 3,000
Self Diagnostics: Laser power supply, laser current, laser power, photo detector power supply, background voltage, photo detector health.
Enclosure: 316L Stainless Steel
Power: 24 VDC 120W
Internal Vacuum Pump: 1.0 CFM with HEPA Filtered Exhaust
Calibration: ISO 21501-4 Compliant and Accredited ISO 17025
Zero Count Level: < 1 Count / 5 minutes (meets specifications of JIS B 9921 and reporting requirements of ISO 21501-4 Annex C)
Software: LMS Pro or LMS Xchange
Weight: 3.1 lbs (1.4 kg)
Dimensions: 4.87”(h) x 6.50”(w) x 3.26”(d) [12.37 x 16.51 x 8.28 cm]
Includes: Power adapter and power cord, Operators Manual on USB flash drive, Calibration Certificate
Optional: Temperature & humidity probe, Wall Bracket, Smart Bracket, Isokinetic sample probe, Printed operators manual
