Gain: 1.6 dBi
VSWR: 2
Style: Stubby Right Angle
Width: 17.1 mm
Length: 18.6 mm
Diameter: 7.4 mm
Bandwidth: 300 MHz
Impedance: 50 Ohms
Wavelength: 1/4 Wave
Application: Bluetooth, WiFi, Zigbee, Thread
Unit Weight: 7.573 g
Polarization: Linear
REACH - SVHC: Details
Mounting Style: Panel Mount
Electrical Type: Monopole
Number of Bands: 1 Band
Center Frequency: 2.45 GHz
Mechanical Style: Whip
Ground Plane Size: 102 mm x 102 mm
Maximum Frequency: 2.6 GHz
Minimum Frequency: 2.35 GHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: SMA Male
Protocol - WiFi - 802.11: WiFi
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
