Gain: - 0.2 dBi
VSWR: 1.9
Style: Stubby Right Angle
Length: 53.5 mm
Diameter: 9.4 mm
Bandwidth: 50 MHz
Impedance: 50 Ohms
Wavelength: 1/4 Wave
Application: Bluetooth, WiFi, Zigbee, Thread
Unit Weight: 8.706 g
Polarization: Linear
REACH - SVHC: Details
Mounting Style: Panel Mount
Electrical Type: Monopole
Number of Bands: 1 Band
Center Frequency: 2.45 GHz
Mechanical Style: Whip
Ground Plane Size: 102 mm x 102 mm
Maximum Frequency: 2.5 GHz
Minimum Frequency: 2.35 GHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: SMA Male
Protocol - WiFi - 802.11: WiFi
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 20 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
