Gain: 1.6 dBi
VSWR: 1.9
Style: Straight
Length: 105 mm
Diameter: 14.5 mm
Bandwidth: 250 MHz
Impedance: 50 Ohms
Cable Type: 216 mm RG174
Wavelength: 1/2 Wave
Application: FirstNet/Public Safety, Sensing, Remote Monitoring, Handheld Devices
Unit Weight: 21.203 g
Cable Length: 216 mm
Polarization: Linear
Mounting Style: Panel Mount
Electrical Type: Dipole
Number of Bands: 1 Band
Center Frequency: 2.45 GHz
Mechanical Style: Whip
Ground Plane Size: 102 mm x 102 mm
Maximum Frequency: 2.6 GHz
Minimum Frequency: 2.35 GHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Protocol - WiFi - 802.11: LoRaWAN, Sigfox, WiFi, WLAN
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE)
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
