Gain: 2.9 dBi
VSWR: 1.9
Style: Straight
Width: 14.5 mm
Height: 9.7 mm
Length: 178 mm
Diameter: 14.5 mm
Bandwidth: 70 MHz
Impedance: 50 Ohms
Wavelength: 1/4 Wave
Application: ISM, Remote Control, Alarms, Security Systems
Unit Weight: 22.355 g
For Use With: 410 MHz, LTE Band 87, LTE Band 88, Personal Mobile Radio - PMR
Polarization: Linear
Mounting Style: Panel Mount
Electrical Type: Monopole
Number of Bands: 1 Band
Center Frequency: 418 MHz
Mechanical Style: Whip
Ground Plane Size: 102 mm x 102 mm
Maximum Frequency: 450 MHz
Minimum Frequency: 380 MHz
Termination Style: Connector
Antenna Connector Type: SMA Male
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM
