Gain: - 2.3 dBi
VSWR: 2.3
Style: Tilt/Swivel
Width: 26.8 mm
Length: 193.5 mm
Diameter: 7.62 mm
Impedance: 50 Ohms
Wavelength: 1/2 Wave
Application: Low Power Wide Area Applications, ISM Applications, IoT Devices, Remote Control, Monitoring, Sensing, Smart Home Networking, Gateways
Unit Weight: 15 g
Polarization: Linear
Power Rating: 10 W
Mounting Style: Panel Mount
Electrical Type: Dipole
Number of Bands: 1 Band
Center Frequency: 868 MHz
Mechanical Style: Whip
Ground Plane Size: 102 mm x 102 mm
Maximum Frequency: 876 MHz
Minimum Frequency: 862 MHz
Termination Style: Connector
Protocol - Sub GHz: RFID
Antenna Connector Type: RP-SMA Plug
Protocol - WiFi - 802.11: LoRaWAN, Sigfox
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 20 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS
