♦ Meets the requirements of CIE, IEC, IES LM-79 & GB standards
♦ Reaching many measurement ways such as B-Beta & C-Gamma (LSG-1800) and C-Gamma (LSG-1700)
♦ The tested luminaries rotates around an angle of (γ)±180°(or 0-360°) and the tested luminaries rotates around itself with an angle of (C)±180°(or 0-360°)
♦ Luminosity Testing Range:
Illuminance 0.001lx~10,000lx;
Light Intensity 1.0cd～10^7 cd(detector)
♦ Angle accuracy: 0.2°
♦ Photometry Accuracy: CIE Class A
♦ Testing Accuracy: 3% (Under Standard lamp); Stray Light: less than 0.2%
♦ English version software can run in Win7, Win8 or Win10
The max size for the Testing Lamp (Unit: mm)
C-Gamma Test with one Pillar: 1600*550
B-Beta Test with two Pillars: 700*600
Max Weight: 50kg
System Configuration:
A. Goniophotometric System
B. SLS-200W AC Standard Light Source
C. LS2012 Digital Power Meter
D. AC Power Source to give a stably AC Output for luminaries test
E. CASE-19IN 19inch Standard Instruments Cabinet (Only LSG-1800 function)
F. Two sets of luminaries Clamps
G. Oversea Delivery Packing: all of the instruments and accessories will be packed to meet long distance sea delivery
