Maximum Range(Max): 620g
Division value(d): 1mg
Repeatability (typical error) (5% load): 1mg
Repeatability (typical error) (5% load): 2mg
Linear error (Typical error): 3mg
Sensitivity drift (+10℃-+30℃): 5 ppm/K
Typical stability time: 2 second
Pan size: φ40mm
Boundary dimension: 230mm×56mm×88.5mm
Input voltage: DC24V±10%, 0.1A
Level of protection: IP54, IP65 match
Ambient temperature: 10℃~30℃
Ambient humidity: 30%~85%
Interface specification: RS232, RS485
Communication protocol: DAT232, DAT485(MODBUS), customization
