Roughness parameters: Ra, Ry, Rq, Rz, Rt, RSm, RS, Rp, Rv, R3z, RSk, Rmax, Rmr
Measuring range: Ra:0.005-16μm Rz:0.02-160μm
Resolution: 0.001μm
Maximum driving trip: 17.5mm/0.7inch
Sample length/Range (L): 0.25mm, 0.8mm, 2.5mm/±20μm,±40μm,±80μm
Evaluation length: 1.25mm, 4mm,5mm/Option from(1-5)L
Filtering methods: RC, PC-RC, GAUSS, D-P,
Error of indication: ≤±10%
Variation of indication: <6%
Memory: 100 Groups
Operating temperature: 0 ºC -40 ºC
Weight: 440g
Dimensions: 119×47×65mm
Standard configuration: Main Unit,Standard sensor,Calibration block, Supporting platform, Power charger, Manual,Certificate, Warranty card, PC analysis software
Optional Accessories: Measurement Platforms , optional sensors, printer
