Application:
Widely used in: electronic consumer goods, can only wear, wire material, automobile, motorcycle industry, battery industry, valve pipe fittings, connection pipe, solenoid valve, lamps and lanterns, fire equipment, military supplies, household appliances and other fields
Specification:
Low pressure
Resolution: 1pa
Positive pressure test: 1~130kpa
Negative pressure test: NO
I/O Interface: 7 input signals / 7 output signals
Test volume: The test product volume is less than 10 liters, the smaller the volume, the faster the test speed.
Historical data: Historical data records show
Test time: Prepare1–prepare 2–pressurized–balance–detection–exhaust–remove | Range:0.1s~~999.0s
Size: D310*W310*H210(mm)
Weight: About 8KG
Power: AC 220V±10%, 50/60HZ, Consumption of electricity: 50VA
Test pressure source: Dry clean air source with high flow and stable pressure
Ambient temperature and humidity: Use of temperature: 5~40℃, storage temperature -20℃~70℃, below 80%RH, But no condensation
