Injection System
Screw Diameter: 26 / 28 / 30 mm
Injection Pressure: 1530 / 1278 / 886 kg/cm²
Theoretical Injection Capacity: 61 / 70.8 / 81 cm
Injection Quantity (g): 56 / 64 / 74 g
Injection Quantity (OZ): 2 / 2.3 / 2.6 OZ
Injection Rate: 57 / 66 / 76 cm/sec
Screw Trip: 115 mm
Screw Revolution: 0–205 rpm
Nozzle Contact Force: 4.45 Tons
Nozzle Trip: 170 mm
Number of Temperature Control Sections: 3
Clamping System
Clamping Force: 35 Tons
Board Size: 450 × 280 mm
Die Column Spacing: 265 mm
Minimum Mold Size: 100 / 25 mm
Opening Stroke: 190 mm
Maximum Die Spacing: 290 / 215 mm
Ejection Pressure: 1.5 Tons
Ejection Stroke: 135 mm
Power & Electrothermal System
Maximum Hydraulic Pressure: 140 kg/cm²
Pump Discharge Volume: 34.5 L/min
Dynamic Oil Quantity: 100 L
Cooling Water Consumption: 400–600 L/hr
Motor Power: 3.75 KW / 5.5 HP
Electric Capacity: 2.4 KW
Total Power Consumption: 6.3 KW
Others
Machine Weight: 1.7 Tons
Mechanical Dimensions (L×W×H): 1.5 × 1.05 × 2.72 m
