Barrel parameters: Inner hole 9.55±0.025mm
Pistons parameters: Piston head: 9.475±0.015mm
Outlet length:8.000±0.025mm
Paramters: Extrusion hole 1=2.095±0.005mm
Temperature parameter
Temperature fluctuation: ±0.2 ℃
Temperature uniformity: ±1℃
Temperature display resolution: 0.1℃
Display resolution: 0.1℃
Maximum comsuption: < 600W
Time display resolution: 0.1s
Weight parameters are as follows:
Weight accuracy: ±0.5%
Basic configuration: A 0.325kg, B 1.2kg, C 2.16kg, D 3.8kg, E 5kg, F 10kg, G 12.5kg, H 21.6kg
Position detection
Control precision: ± 0.1mm
Test flow control
Times of cutting the material: 0~10 times
Material cutting interval :0~999s(set reference Table 2)
Control flow reaches the set temperature without volatility
Barrel temperature time: 15 min.
Material be installed: 1 min.
Material sample temperature recovery time:4 min.
When binder set: 1min
Output mode: Micro-automatic print output
Cut material methods: The hand automatic cut into one body
Test load: Eight sets of weights
Power: AC220V±10% 50/60HZ
