Sample max weight: 0-200Kg
Drop height: 0-1500 mm
Max sample size: 1600×1100×1000mm
Impact floor size: 1800 × 1600mm
Impact bottom
1. One piece: 30mm thick, flat: the height difference of any two points on the impact surface
shall not exceed 1mm；
2. Hard: the static load deformation of any 100mm2 area on the impact surface shall not exceed 0.1mm
Sample hoisting speed: <20s/m
The arm drops the terminal velocity: 1m height, terminal velocity >4.42m/s
Support arm: size 1000 × 1000 × 30ｍｍ
Test side: Face, edge, Angle
Power: 380V/50HZ
Drive way: Motor drive
Protection device: The upper and lower protective devices are provided with induction type protection
Impact sheet materia:l 45# Steel, Solid steel plate
Height shows: Touch screen control
Drop height: Touch screen control
The structure of the bracket arm: 45# Steel is made by welding
Drive way: Straight sliding block and copper guide sleeve imported from Taiwan, 45#Chrome steel
Accelerating device: pneumatic
Drop way: pneumatic
Weight: About 1500KG
Rate of power: 5KW
