Ludatest YAW-300 Automatic Compression Testing Machine (300 kN)

Description:

This product is suitable for compressive strength test of brick, stone, cement, concrete and other materials, and can also be used for compressive testing of other materials. After setting up the concrete anti folding device, the machine can make concrete bending resistance and mortar compressive test. 300KN automatic compression testing machine adopts high precision digital micro-valve with force closed-loop control function. It can realize equal load rate loading or equal stress rate loading. It has high control precision and good reliability.

Specification:

Max Test Force: 300 kn

Measure Range: 5-100 %

Load Indication Accurancy: ±1/±0.5 %

Max Pressing Space: 190 mm

Bearing Plate Diameter: Φ140 mm

Oil Pump Motor Power: 0.75 kw

Machine Size: 880*440*1200 mm

Net Weight: 400 kg
