Measuring range for outer measurement (mm): 0 ~ 1000
Measuring range for inner measurement (mm): 0.5 ~ 845
Direct measuring range (mm): 300
Position deviation / error limit (L in mm) (µm): ≤ (0.04+ L/2000)
Measuring uncertainty MPEE1 (L in mm) (µm): ≤ (0.055 + L/1500)
Measuring forces (N): 0 to 13.9
Repeatability (µm): ≤ 0,03
Contacting speed with joystick: 8 mm/s
Device length (mm): 2500
Mass (kg): 840
Table surface (A x B) (mm): 150 x 350
Accessories
Large number of accessory kits and modular components for completing a wide variety of measuring tasks, including the measurement of
Thread gages
Conical thread gages
Gears
Thread pitches
Factory calibration or DAkkS/DKD calibration can be additionally offered for this measuring station
