Max. workpiece weight [kg]: 300 (on fixed base plate) 100 (on centering and tilting table)
Mass [kg]:2250
Accuracy: Accuracy class I for gear measurements in accordance with VDI/VDE 2612/2613 Group 1 at 20°C ± 2°C
Axial runout deviation (µm+µm/mm measuring radius): 0.07 µm + 0.0008 µm/mm
Footer text: *max. diameter of spur gears
Radial runout deviation (µm in table height): ≤ 0.1 µm
Measuring path Z (mm): 700
Measuring path Y (mm): 600
Diameter max.* [mm]: 600
Distance between peaks [mm]:1000
Measuring path X (mm): 300
ACCESSORIES
• Probe arm changer (4 boxes)
• Anti vibration damping system
• XXL centering and tilting table (centering path up to ± 72 mm)
• Tailstock 1000 mm
