Start of traversing length (in X):0 mm
End of traversing length (in X):280 mm
350 mm Z-axis
With angle adjustment of the X-axis
Positioning speed: 0.02 – 200 mm/s (in X)
Guide deviation:0.07 µm / 20 mm (with probe system BFW 250),0.35 µm / 60 mm,0.4 µm / 140 mm
Measuring speed: Up to 10 mm/s
Measuring range:
- With probe system BFW 250:
500 µm (±250 µm) for probe arm length 45 mm
1500 µm (±750 µm) for probe arm length 135 mm
- With probe system C 11:
70 mm with probe arm length 350 mm
max. 100 mm with probe arm length 490 mm
ACCESSORIES
Optional
• Manual control panel with joystick and display
• Motor-driven TY axis
• Parallel vice
• Prism block
• Equipment table
• Vibration damping system
General software options
• Option - MeasurementPlus
• Option - RoughnessPlus
• Option - ContourPlus
• Option - Dominant Waviness (WDc) for MarWin
• Option - ISO 13565-3 surface parameters
• Option - QS-STAT / QS-STAT Plus
• Option - Profile processing
• Option - User-defined parameters
• Option - Topography
