APPLICATIONS
Calibration of:
• Plain plug gages and gage rings
• Setting gage rings
• Snap gages
• Spherical gage blocks, internal micrometers
• Gage blocks
• Thread gages
• Taper thread gages
• Gear gages
• Taper gages
• Dial indicators
• Dial comparators
• 2-point bore gages
• Outside micrometers
• 2-point inside micrometers
• Length measurement on precision table
Direct measuring range [mm]:100
Measuring range for outer measurement [mm]:0-1060
Measuring range for inner measurement [mm]: 0.5-905
Measuring uncertainty MPEE1(L in mm) [µm]: ≤ (0.09+L/2000) or ≤ (0.3+L/1500)
Repeatability [µm]: ≤ 0.5 or 0.1
Measuring forces [N]: 0.2 ; 1.0 to 4.5 ; 11
Device length [mm]: 1500
Mass [kg]: 215
ACCESSORIES
• Large number of accessory kits and modular components for completing a wide variety of measuring
tasks, including the measurement of:
• Thread gages
• Taper gages
• Conical thread gages
• Gears
• Factory calibration or DAkkS/DKD calibration can be
additionally offered for this measuring station
