Load capacity*: 750 lbF[3.4 kN]
Maximum travel: 14.2 in [360 mm]
Speed range: 0.001 - 60 in/min [0.02 - 1,525 mm/min]
Load accuracy (% of full scale)
+ Test frame + force sensor, calibrated together: ±0.1%
+ Test frame alone: ±0.1%
+ Force sensor alone: Series FS05: ±0.1% | Series R06: ±0.15% | Series R07: ±0.15%
Speed setting accuracy: ±0.2%
Peak sampling rate: 20,000 Hz
Data acquisition rate: 1,000 Hz
Speed accuracy: ±0%, stepper motor driven
Distance accuracy: ±0.002 in [0.05 mm], at any load or position, factory-compensated
Distance resolution: 0.0005 in [0.01 mm]
Limit switch repeatability: ±0.001 in [0.03 mm]
Overload protection: Motor stops at 120% of full scale of the force sensor
Power: Universal input 100-240 VAC, 50/60 Hz, 300W
Fuse type: 4A, 3AG, SLO BLO
Weight (test frame only): 149 lb[68 kg]
Environmental conditions:
+ Indoor use only
+ Up to 6,500 ft [2,000 m] above sea level
+ Temperature range: 40 - 95°F [5 - 35°C]
+ Humidity range: up to 80% relative humidity at 31°C, decreasing linearly to 50% relative humidity at 40°C, non-condensing
+ Mains supply voltage fluctuations up to ±10% of the nominal voltage
+ Transient overvoltages up to the levels of Overvoltage Category II
+ Use in environments up to Pollution Degree 2
Conformance:CE, UKCA
*Load capacity is reduced at higher speeds, as follows:
- F755 / F755S: limited to 500 lbF [2.3 kN] above 35 in [900 mm]/min
- F1505 / F1505S: limited to 1,000 lbF [4.5 kN] above 60 in [1,525 mm]/min
