Capacity x Resolution: 25 lbFin / 400 ozFin / 28 kgFcm / 290 Ncm / 2.9 Nm
Accuracy: ±0.3% of full scale
Sampling Rate: 7.000 Hz
Power:
AC adapter: 100-240VAC, 50-60 Hz, 0.3 A
Battery: Rechargeable 8.4V NiMH
Low battery indicator appears when battery level is low, and gauge powers off automatically when power reaches critical stage
Battery life: Backlight on: up to 7 hours of continuous use
Backlight: up to 24 hours of continuous use
Units: ozFin, lbFin, kgFcm, Nm, Ncm
Outputs:
USB / RS-232: Configurable up to 115,200 baud.
Mitutoyo: Serial BCD suitable for all Mitutoyo SPC-compatible devices
Analog: ±1 VDC, ±2% of full scale at capacity
General purpose: Three open drain outputs, one input
Set points: Three open drain lines.
Safe overload: 150% of full scale (display shows “OVER” at 110% and above)
Weight: 5.8 lb [2.6 kg]
Environmental requirements: 40 - 100°F, max. 96% humidity, non-condensating
