Capacity x Resolution: 200 x 0.1 lbF | 3200 x 2 ozF | 100 x 0.05 kgF | 1,000 x 0.5 N | 1 x 0.0005 kN
Accuracy: ±0.2% of full scale
Wire gauge range*:AWG30 - AWG 3* [0.01 - 0.25 in (0.3 - 6.3 mm) dia.]
Sample length range:2.1 in [53.3 mm], excluding termination
Max. elongation:2.3 in [58.4 mm]
Speed range:Test/Pull Speed: 0.4 - 12.0 in/min [10 - 300 mm/min]
Approach/Preload Speed: 12.0 - 20.0 in/min [300 - 500 mm/min]
Return Speed: 12.0 - 45.0 in/min [300 - 1,125 mm/min]
Speed setting accuracy:±0.2%
Speed variation with load:±0% [Stepper motor driven]
Power:Universal input 80-240 VAC, 50/60 Hz
Sampling rate:7,000 Hz
Outputs:USB / RS-232: Configurable up to 115,200 baud.
Mitutoyo: Serial BCD suitable for all Mitutoyo SPC-compatible devices.
Analog: ±1 VDC at capacity, ±0.25% of full scale.
General purpose: Three open drain outputs, one input.
Set points: Three open drain lines, 40 VDC max., 100 mA DC max.
Overload protection:Motor stops at 120% of full scale of the force sensor (display shows “OVER” at 110% and above)
Weight:28 lb [12.7 kg]
Environmental requirements:40 - 100°F, max. 96% humidity, non-condensing
