Test Frequency:
Range: 10Hz~10MHz
Minimum Resolution: 100mHz, 6-bit Frequency Input
Accuracy: 7 ppm±100mHz
Basic Accuracy: ± 0.05%
AC Measurement:
Test Signal Voltage Level: 10mV - 2Vrms
Voltage Minimum Resolution: 1mV
Accuracy: ALC ON：6% * Voltage ± 2mV / ALC OFF：10% * Voltage ± 2mV
Test Signal Current Level: 200µA - 20mArms
Current Minimum Resolution: 10µA
Accuracy: ALC ON：6% * Current ± 20µA / ALC OFF：10% * Current ± 20µA
DC Measurement: 1V (fixed)
Test Time (The fastest): < 3ms
Output Impedance: 25Ω/100Ω, switchable (Nominal value)
Parameters: |Z|, |Y|, θ, X, R, G, B, L, D, Q, DCR, C, Vdc-Idc, ESR, ε' ε"and μr' μr"
Measurement Mode: Meter mode, list mode
Measurement Circuit: Series/Parallel
Correction: Open Circuit/ Short Circuit/Load correction
List mode: 50 groups of Multi-steps setting (Each group contains up to 15 steps)
BIN: 9
Comparator: ABS, ΔABS, Δ%, OFF
Bulit-in Storge: 100 sets LCR Meter setting documents, 50 sets list mode setting documents
USB Host Storge: LCR setting documents, list mode setting documents, BMP graphics
Interface: RS-232, GPIB, Handler, LAN, USB Host/Device
Power Supply:
Voltage: 90V ~ 264Vac
Frequency: 47Hz ~ 63Hz
Power Consumption: Low power consumption: Maximum 30W (Nominal value)
Display: 7.0”TFT, 800x480 color screen
Environment: Temperature: 10℃ ~ 40℃ Humidity: ≦80%
Dimension (W*H*D): 336x147x340 mm
Weight: 3 kg
