Rated input voltage: AC 110V/220V±10%
Output: All channel outputs are currently isolated and ungrounded
Rated output power: 160W *3CH
Rated output voltage: 0-32V*3CH
Rated output current: 0-10A*3CH
Variable pressure mode: Linear power supply
Maximum voltage when connected in series: 96V
Maximum current when connected in parallel: 30A
Load regulation:
Voltage: ≤ 0.01% + 2mV
Current: ≤ 0.01% + 250mµA
Power supply regulation:
Voltage: ≤ 0.01% + 2mV
Current: ≤ 0.01% + 250mµA
Set value resolution:
Voltage: 1mV
Current: < 1 A / 0.2 mA; ≥1A / 1mA
Setting accuracy (25°C ± 5°C):
Voltage: ≤ 0.05 %+5mV
Current: ≤ 0.1%+ 5mA
Readback value resolution:
Voltage: 1mV
Current: < 1 A / 0.2 mA; ≥1A / 1mA
Readback accuracy(25°C ± 5°C):
Voltage: ≤ 0.05 %+5mV
Current: ≤ 0.1%+ 2mA
Ripple (20Hz-20MHz)
Voltage: ≤1.5 mV (RMS)
Current: ≤1 mA (RMS)
Temperature Coefficient:
Operating environment: 5 to 40°C ≤ 80% R.H
Storage environment: -20 to 70°C ≤ 80% R.H
Sense compensate: Maximum voltage compensation 1V
Remote communication time: Handling < 50 ms
Electronic fuse:
Response time: < 10 ms
Fuse delay: 0 ms to 250 ms (10 ms step)
Interface standard: RS-232+USB; Optional: LAN
Machine size (WxHxD): 285 x136 x405mm
Weight: 14 kg
