Voltage: 0~200V
Current: 0~2A
Power: 400W
Input voltage: AC 220V/110V±10% 50Hz/60Hz
Rated output: voltage: 0~200V, current: 0~2A
Load regulation rate: Voltage ≤ 0.01% + 12mV, Current ≤ 0.2% + 5mA
Line regulation rate: Voltage ≤ 0.01% + 12mV, Current ≤ 0.2% + 5mA
Setting resolution rate: Voltage 10mV Current 1mA
Setting accuracy: Voltage ≤ 0.01% + 80mV Current ≤ 0.1% + 5mA
Readback resolution rate: Voltage 10mV Current 1mA
Readback accuracy: Voltage ≤ 0.01% + 80mV Current ≤ 0.1% + 5mA
Ripple and noise: Voltage ≤ 3mV(rms), Current ≤ 5mA(rms)
Working Temperature: 0~40°C ≤ 80% * RH
Size (mm): 250 * 150 * 330
Net weight kg: 12
Datasheet
Catalog
• It can save the output status and value before the last shutdown
• Current can be pre-set without short circuit
• Current and voltage output can be set in a certain range, which can prevent misoperation from damaging the tested object
• Slow startup circuit design, small surge current
• Voltage compensation function to ensure high precision
• USB, RS-232/485 are optional
• Two groups memory, can be recalled quickly
• One click to restore factory settings
