Rated input voltage: AC220V±10% or 110v±10%
Rated output:
Voltage: 0~32V (CH1, CH2), 2.5V/3.3V/5V (CH3), 5V (CH4(USB))
Current: 0-6A (CH1, CH2), 3A (CH3), 2A (CH4(USB))
Rated output power: 409W
Voltage transformation method: Switching Mode Power Supply
Load regulation rate:
Voltage: < 0.1% + 8mV (CH1, CH2)
Current: < 0.1% + 5mA (CH1, CH2)
Line regulation rate:
Voltage: < 0.1% + 8mV (CH1, CH2), < 0.1% + 10mV (CH3, CH4(USB))
Current: < 0.1% + 5mA (CH1, CH2), < 0.1% + 5mA (CH3, CH4(USB))
Setting accuracy:
Voltage: ≤0.2%+2bit (CH1, CH2), ≤0.2%+2bit (CH3)
Current: ≤ 0.5% + 5mA (CH1, CH2)
Readback accuracy:
Voltage: ≤0.1%+2bit (CH1, CH2), ≤0.1%+2bit (CH3)
Current: ≤ 0.5% + 5mA (CH1, CH2)
Readback resolution:
Voltage: 10mV (CH1, CH2)
Current: 1mA (CH1, CH2)
Ripple (5Hz sim 1MHz ):
Voltage: ≤ 10 mVrms(CH1, CH2, CH3, CH4(USB))
Current: ≤ 5mArms (CH1, CH2, CH3, CH4(USB))
OVP: 0 - (32V ± 0.2)% * FS(CH1, CH2)
Maximum voltage: (32V ± 0.2)%(CH1, CH2)
OCP: 0 - (6.1A ±0.2)% FS (CH1, CH2)
Maximum current: (6.1A ± 0.2)% (CH1, CH2)
Temperature coefficient:
Operating environment: 0 - 40 °C <= 80% RH
Storage environment: -15 to 70°C ≤ 85% R.H
Machine size (WxHxD): 220 x 150 x 330
Net weight: 3.5 kg
Gross weight: 4.3 kg
Datasheet
Catalog
Features
• Five groups of storage, easy to recall
• Power up to 409W
• It can save the output status and value before the last shutdown
• The adjustable range of current and voltage can be set
• One key series parallel connection
• Restore factory settings with one click
• Independent control of three channels
Applications
■Develop and design validation common tests
■Aging of product
■Routine electronic testing and maintenance
■Lab
