Rated output:
Voltage: 0 ~ 61V * 2/0 ~ 6V * 1
Electric current: 0 ~ 3A * 3
Load regulation:
Voltage: ≤0.01%+ 3mV
Electric current: ≤0.01%+ 3mA
Power regulation:
Voltage: ≤0.01%+ 3mV
Electric current: ≤0.01%+ 3mA
Set resolution:
Voltage: 10mV
Electric current: 1mA
Readback resolution:
Voltage: 10mV
Electric current: 1mA
Set accuracy:
Voltage: ≤0.03%+ 2 bytes
Electric current: ≤0.1%+ 5mA
Readback accuracy:
Voltage: ≤0.03%+ 2 bytes
Electric current: ≤0.1%+ 5mA
Ripple and noise:
Voltage rms: ≤2mVrms
Electric current: ≤5mArms
Series and parallel setpoint accuracy:
Voltage: ≤0.02%+ 2 bytes
Electric current: ≤0.1%+ 30mA
Memory:
Store / Call: 40 groups
Features: Timing off output
Timer: time setting: 0.1s ~ 99999.9s
Resolution: 0.1s
Operating temperature: 0 ~ 40 ° C
Bare metal size: mm: 255 * 110 * 380
Packing size: mm: 325 * 210 * 475
Net weight: kg: 8.5
Gross weight: kg: 10
