Width: 25.4 mm (1 in)
Height: 10.2 mm (0.402 in)
Length: 25.4 mm (1 in)
Industry: Industrial
Dimensions: 25.4 mm x 25.4 mm x 10.2 mm
Application: Telecom/Datacom System, Wireless Network, Industrial Control, Instrument, Analyzer, Detector, Data Switch
Unit Weight: 20 g
Output Power: 15 W
Input Voltage: 9 VDC to 36 VDC
Mounting Style: Through Hole
Isolation Voltage: 3 kV
Number of Outputs: 2 Output
Input Voltage - Max: 36 V
Input Voltage - Min: 9 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 1.5 A
Output Current-Channel 2: 1.5 A
Output Voltage-Channel 1: 5 V
Output Voltage-Channel 2: - 5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
