Volume: 14 l
Interior Dimensionsl(A) x w(B) x h(C): 350 x 290 x 140 mm
Casing Dimensions w(D) x h(G) x d(E): 578 x 347 x 436 mm
Temperature sensor: 1 Pt100 sensor class A in 4-wire-circuit
Temperature control: mechanical temperature limiter TB protection class 1 switching the heating off at approx. 30°C above max. temperature of the bath
Temperature control: in case of overtemperature due to failure, the heating is switched off at approx. 10°C above the set temperature (fixed value)
Autodiagnostic system: microprocessor PID-temperature controller with integrated autodiagnostic system with fault indicator
Setting temperature range: +10 to +95 °C and boiling stage
Working temperature range in °C: min. 5 above ambient up to +95 °C with additional boiling mode
Temperature resolution: 0.10C
Voltage: 230 V, 50/60 Hz
Electrical load: approx. 1800 W (during heating)
