APPLICATIONS:
- Building Automations
- Environmental Clean Up Sites
- Air Pollution Level Monitoring
- Dust Level Warning Systems
- Military Applications
- Surface Emissions Modeling
- HVAC Control
- Industrial Hygiene
SPECIFICATIONS:
- Measurement Principles: Particulate concentration by forward light scatter laser Nephelometer
-Available Cut Points: TSP Inlet Standard. PM10, PM2.5, and PM1 sharp-cut cyclone inlets available.
-Measurement Range: 0 to 100 mg/m3 (0 to 100,000 µ g/m3)
-Measurement Sensitivity: .001 mg/m3.
-Nephelometer Accuracy: ± 5% traceable standard with 0.6um PSL.
-Particle Size Sensitivity:0.1 to 100 micron. Optimal sensitivity 0.5 to 10 micron particles.
-Display:2 X 16 back lit LCD. Provides information on operation including: Power, Flow Operation, Status and Concentration.
-Zero Calibration: Automatic Zero Calibration every hour or as programmed from 1 to 999 minutes.
-Flow Rate: 2.0 liters/minute ± 0.1 lpm
-Power: 15 – 40 VDC @ 1.5 A maximum
-Power Consumption: 350 mA (no heater) 1.1 A (with heater) @ 15 VDC
-Analog Output: 4-20 mA and 0 – 10 VDC
-Digital I/O: RS-485 full and half duplex, RS-232
-Serial Communication: ASCII Text data and MODBUS RTU
-Alarm Output: Normally open and normally closed relay 30 VDC @ 1A maximum
-Operating Temperature: 0 to +50°C (Ambient Temperature Sensor Range -30 to +50°C)
-Barometric Pressure: 600 to 1040 mbar pressure sensor range
-Ambient Humidity Range: 0 to 90% RH, non-condensing
-Intake Moisture Control: Automatic 10 Watt inlet heater module controlled to sample RH set point.
-Factory Service Interval: 24 Months typical, under continuous use in normal ambient air.
-Mounting Options: Wall mount bracket standard, or EX-905 tripod
-Unit Weight: 2.27 kg ( 6.0 lbs)
-Unit Dimensions:22.9cm high, 17.8cm wide, 10.8cm deep, (9.0” x 7.0” x 4.25”), w/out inlet assy.
48.3cm high, 17.8cm wide, 10.8cm deep, (19.0” x 7.0” x 4.25”), w/ inlet assy.
