Dimensions: 930 x 690 x 590 mm / 3.1 x 2.3 x 2 ft
Support surface: 1000 x 505 x 365 mm
Maximum cutting width 90°/45°: 305 / 214 mm // 12 / 8 7/16 "
Maximum cutting depth at 90°/45°: 90 / 54 mm // 3 9/16 / 2 1/8 "
Cutting capacity 90°/90°: 305 x 90 mm / 12 x 3 9/16 "
Cutting capacity 45°/45°: 214 x 54 mm / 8 7/16 x 2 1/8 "
Turntable setting left/right: 47 / 60 °
Saw blade tilt left/right: 46 / 46 °
Saw blade: 254 x 30 mm / 10 x 1.181 "
Rated input power: 1400 W
Rated input power S1 100%: 1400 W
Rated input power S6 20%: 2000 W
No-load speed: 3900 - 5150 rpm
Revolutions at rated load: 5150 rpm
Cutting speed: 44 - 68 m/s // 144 - 223 ft/s
Weight: 26.8 kg / 59 lbs kg
Cable length: 2 m / 7 ft
Noise emission
Sound pressure level: 88 dB(A)
Sound power level (LwA): 96 dB(A)
Uncertainty of measurement K: 2.6 dB(A)
Delivery
Carbide saw blade (60 teeth)
Adapter 35/58 mm
2 x Table length extensions
Material clamp
Accessories
SAWING
Circular saw blades, Other accessories for semi-stationary/stationary circular saws, Further accessories for crosscut and mitre saws, Further accessories for band saws, Other accessories for semi-stationary/stationary saws
OTHER ACCESSORIES
Occupational safety
Datasheet
Features
Maximum flexibility when sawing thanks to rotating table and inclinable saw head on both sides
Speed control for extended range of application, e.g. for cutting of aluminium profiles and plastics
Sliding function for wide work pieces.
Easy transport thanks to ergonomically-designed handles and saw head lock
Superb dust extraction capability thanks to a dual extraction port design aligned closely to the work piece.
Vario-Constamatic (VC)-Full wave electronics for working at customised speeds to suit the application materials, and speeds that remain almost constant even under load
Metabo Quick for changing saw blades without tools
Soft start for long service life of motor and drive
Fast and precise setting of common angles using stop points
Sliding high rear fence profiles for safe sawing
Material clamp for secure fixing of the work piece from the top or front
Integrated, pull-out table width extensions made from die-cast aluminium
Depth guide for easy creation of grooves
All scales and operating elements are visible from the working position and can be operated intuitively
