Direct access to our certified experts
Dimensions: 1110 x 620 x 960 mm / 3.7 x 2.1 x 3.2 ft
Dressing plates L x W: 1040 x 260 mm / 3.4 x 0.9 "
Chip removal, planing: 0 - 3 mm // 0 - 1/8 "
Chip removal bench thicknesser: 0 - 3 mm // 0 - 1/8 "
Material dressing plates: Cast aluminium
Material thickness table: Grey cast iron
Thickness table L x W: 400 x 260 mm / 15 3/4 x 10 1/4 "
Passage height/width: 160 / 260 mm // 6 5/16 / 10 1/4 "
Feed rate: 5 m/min / 16 ft/min
Diameter of blade shaft: 63 mm / 2 1/2 "
Number of blades: 2
Revolutions of blade shaft: 6500 rpm
Mains voltage: 380 - 415 V
Rated input power: 2800 W
Output power: 2000 W
Weight: 71 kg / 157 lbs
Noise emission
Uncertainty of measurement K: 3 dB(A)
Delivery
Integrated disposable reversible planer blades
Push stick
Extraction Nozzles
Transport wheels
Short, swivelling jointing fence
Chip ejection hood
Accessories
SAWING
Other accessories for semi-stationary/stationary saws
OTHER ACCESSORIES
Occupational safety
Datasheet
Features
Simple conversion from surface planer to bench thicknesser without tools
Stable gear for uniform work piece feed
Thickness table made of solid, non-abrasive grey cast iron
Convenient height adjustment with crank handle
Planer blades with double blade for longer service life
Jointing fence, swivelling 90°-45°
Powerful universal motor for powerful lugging drive and even planing result
Quiet induction motor, maintenance-free and robust.
Restart protection: prevents unintentional start-up after power supply interruption
High torque three-phase motor
