Dimensions: 834 x 639 x 1860 mm / 2.8 x 2.1 x 6.1 ft
Support surface: 536 x 640 mm / 21 1/16 x 25 1/8 "
Working height without stand: 925 mm / 36 1/2 "
Sawing bench swivel range: 0 - 20 °
Cutting height: 280 mm / 11 "
Passage width: 440 mm / 17 3/8 "
Cutting speed: 430 m/min / 1020 m/min m/min
Saw belt length: 3380 mm / 133 "
Mains voltage: 220 - 240 V
Rated input power: 1500 W
Output power: 1100 W
Weight: 133 kg / 293 lbs
Noise emission
Sound pressure level: 82 dB(A)
Sound power level (LwA): 90 dB(A)
Uncertainty of measurement K: 4 dB(A)
Delivery
Universal band saw blade A6
Parallel Guide / Rip Fence
Extraction nozzle (Ø 100 mm)
Accessories
SAWING
Band saw blades, Further accessories for band saws, Other accessories for semi-stationary/stationary saws
OTHER ACCESSORIES
COccupational safety
Datasheet
Features
High precision and stability for highest cutting quality
Two cutting speeds for various applications and materials
Top and bottom HSS precision three-roller guide of the band saw blade for best cutting results, adjustable without tools
Quiet induction motor, maintenance-free and robust.
Restart protection: prevents unintentional start-up after power supply interruption
Easy inclination adjustment of the grey cast iron saw table for precise incline cuts thanks to toothed ring guide
Door opening without tools for easy saw blade change
Viewing window for blade clamp indicator for fast control of the blade clamping from outside
Tool-less height adjustment of the saw blade guard
Attachments can be stored in the saw housing
External extraction possible for low-dust working
Radius cutting with circle sawing attachment (accessory)
