METONE 010C Wind Speed Sensor (0~135mph)

Performance Characteristics

Maximum Operating Range: 0~135mph (0~60m/s) Starting Speed: 0.5mph (0.22m/s)

Calibrated Range: 0~112mph (0~50m/s)

Accuracy: ±1% or 0.15mph (0.07m/s)

Resolution: <0.1mph or m/s

Temperature Range: -50~65°C (-58°F~149°F)

Distance Constant: less than 5It (1.5m) of flow (meets EPA specifications)

Electrical Characteristics

Power Requirements: 12VDC at 10mA, 12VDC at 350mA for internal heater

Output Signal: 11 volt (pulse frequency equivalent to speed)

Output Impedance: 100Ω maximum

Physical Characteristics

Weight: 1.5Ibs (0.68kg)

Finish: Clear anodized aluminum; Lexan cup assembly

Cable & Mounting

PN 1953: Cable Assembly; specify length in feet or meters

Mounting: PN 191 Crossarm Assembly

Datasheet

Manuals
