Power Supply: 5~24VDC with a nominal current draw of 300uA
Output (Sensitivity): 2mV/Wm2
Calibration Factor (Reciprocal
of Output): 0.5Wm2/mV
Calibration Uncertainty: ±5%
Measurement Repeatability: < 1%
Long-Term Drift: <2% per year
Non-Linearity: <1% up to 1250Wm2
Response Time: <1ms
Field of View: 180°
Spectral Range: 360~1120nm
Directional Response: ±5% at 75° zenith angle
Temperature Response: 0.04 ±0.04% per C
Operating Environment: -40~70° C; 0~100% Relative Humidity
Dimensions: 24mm diameter, 28mm height
Mass: 140g
Cable: 5m shielded, twisted-pair, santoprene rubber jacket
