PERFORMANCE
Particle Size Range: >0.3, >0.5, >0.7, >1.0, >2.5, >5.0 and >10.0 μm (selectable)
Concentration Range: 0 – 3,000,000 particles per cubic foot (105,900 particle/L)
Accuracy: ± 10% to calibration aerosol
Sensitivity 0.3 μm
Flow Rate: 0.1 cfm (2.83 lpm)
Sample Time: Adjustable 3 to 60 seconds
Status Indicators: Low Battery, Service
ELECTRICAL
Light Source: Laser Diode, 30mW, 780 nm
Power: 7.2V Lithium Ion self-contained battery pack—provides 30 hours of typical intermittent operation, up to 8 hours continuous use
AC Adapter/Charger: AC to DC module intelligent Lithium Ion charger, 100 – 240 VAC to 8.4 VDC @ 1500 mA typical. Charge time 2.5 hours typical
Communications USB
Certifications: Meets or exceeds CE, ISO, ASTM, and JIS international certifications
INTERFACE
Display: 2 line by 16-character LCD
Keyboard: 2-button membrane
PHYSICAL
Size Height: 6.75” (17.2 cm) Width: 3.75” (9.5 cm) Thickness: 2.0” (5.1 cm)
Weight: 1.31 lb (21 oz) (0.60 kg)
ENVIRONMENTAL
Operating Temperature: 0˚ to +50˚C
Storage Temperature: -20˚ to +60˚C
INCLUDED ACCESSORIES
+ Operation Manual
+AC to DC Converter Module with IEC AC Power Cord
+NIST Traceable Calibration Certificate
+USB Cable
+Software
OPTIONAL ACCESSORIES
+Optional Carrying Case (P/N 8517)
+Protective Boot (P/N 80450)
+Zero Filter Kit (P/N 80846)
+Flow Meter Kit (P/N 80530)
