METRIX AX 501 Laboratory Power Supply (30VDC/2.5A)

Name: METRIX AX 501 Laboratory Power Supply (30VDC/2.5A)
Brand: METRIX
Availability: OutOfStock

ManufacturerMETRIX(View more products from this manufacturer)

ModelAX 501

P/NAX0501A

OriginFrance

Warranty12 months

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

- Technology : Linear
- Number of outputs : 1
Voltage Regulation
- Output 1 :0 to 30 VDC
- Display Resolution :100 mV
- Basic Accuracy :± 0.5%R + 1D
- Residual Ripple :< 1 mV RMS
Current Regulation
- Output 1 :0 to 2.5 A
- Resolution :10 mA
- Basic Accuracy :± 0.5%R + 1D
- Indication of limitation :LED channels 1
- Short-circuit protection :Electronic current limitation
- Protection against overheating :Temperature control
Stability for variation
- of ± 10% in mains : ± 0.03%R + 2 mV
- of 0 to 100% in load : ± 0.02% R + 5 mV
GENERAL SPECIFICATIONS
- Display: 3 digits – green LED’s. Simultaneous V and I / Output 1
- Fine and coarse adjustment : Output 1
- Connections: Two-pin safety terminals. Male safety earth yellow/green
- Reference temperature :23°C ± 5°C
- Operating temperature :0 to 50°C
- Power requirements :110 VAC ± 10% / 60 Hz; 230 VAC ± 10% / 50 Hz
- Dimensions (W x H x L) :225 x 120 x 270 mm
- Weight : 4 kg
- Safety :IEC 61010– Class 1– Pol. 2; Output : Cat.I, 100 V; Mains Supply : Cat.II, 300V

State at delivery: 1 power supply delivered with 1 mains power cable and 1 user manual

Datasheet
User guider

METRIX AX 501 Variable Power Supplies

Ultra-safe, lightweight, economical and modern

This power supply is lightweight, economical but sturdy, generating very low radiation.

It is very safe and provides electronic current limitation in the event of a short-circuit, as well as temperature control if overloads or overheating occur.

The outputs have dual insulation in relation to the mains by means of double-well safety terminals, even for the earth socket.

Metrix AX501: Stabilised Laboratory Power Supplies

Linear technology
Green and red, 3-digit LEDS
1 x30V/2.5A outputs
TRACKING Mode
110 and 230V power supply
Dimensions: 120x225x270 mm
Weight: 4kg
