- Clamping Ø 26 mm
- Display: 4,000 counts
- Bargraph: 42 segments
- Range change: Automatic
- Function keys: HOLD
- IEC 61010-1 and IEC 61010-2-032 safety norms: Cat.III, 300 V - Cat.II, 600 V
- Operating temperature: 0 to 40°C (<70% HR)
- Storage temperature: -10 to 60°C (<80% HR)
- Power supply: 2 x 1.5 V LR03
- Battery charge life: 100 h
- Auto cut-off: 30 min
- Dimensions: 193 x 50 x 28 mm/ Weight: 230 g
TECHNICAL SPECIFICATIONS
- AC current
+ Measuring range: 0.05 to 400.0 A (in 2 calibres)
+ Basic accuracy: 1.9%L + 5D
+ Bandwidth: 50 to 500 Hz
+ Protection: 600 A RMS
- AC voltage
+ Measuring range: 0.5 V to 600 V (in 2 calibres)
+ Basic accuracy: 1.5%L + 5D
+ Bandwidth: 50 Hz to 500 kHz
+ Input impedance: 1 MΩ
+ Protection: 660 VRMS
- DC voltage
+ Measuring range: 0.2 to 600 V (in 2 calibres)
+ Basic accuracy: 1%L + 2D
+ Protection: 660 VRMS
- Resistance
+ Measuring range: 0.2 to 399.9 Ω
+ Basic accuracy: 1%L + 2D
+ Max. open circuit voltage: 1.5 VDC
- Continuity with buzzer
+ Detection threshold: ≤40 Ω
- Frequency
+ Measuring range :Current: 20 Hz to 10.00 kHz (in 2 calibres); Voltage: 2 Hz to 1 MHz (in 4 calibres)
+ Basic accuracy: 0.1%L + 1D
+ Sensitivity: 2-5 A RMS/ 5-10 V RMS
Delivered with carrying bag containing:
a set of measuring leads, a carrying bag, a user's manual and two 1,5 V alkaline batteries
