Model Family: 4-electrode sensor
Sterilizable: Yes
Cell Constant: 0.25 cm-1
Sensor Material: PEEK (FDA)
System accuracy: ± 5 % or better
Cable Connection: Vario Pin (IP 68)
Measurement Range: 0.02-650 mS/cm
Electrode Material: Sterilizable, 316 L
Process Connection: 2 inch TC
Temperature Sensor: PT 1000
Measurement Technology: Conductive
Cell Constant (nominal): 0.25 cm–1
Hazardous Area Approvals: Yes
Primary Media/Application: Chemical Processes Other Industrial Processes Other Water Processes Pharmaceutical Waters Pharmaceutical/Life Science Production
Measured Pressure Resistance: 0 – 100 psig @ 203 °F 0 – 246 psig @ 77 °F (0 – 17 barg @ 25 °C 0 – 7 barg @ 95 °C)
Operating Temperature (Celsius): -10...140 °C
Operating Temperature (Fahrenheit): 14...284 °F
Hygienic/Biocompatibility Approvals: No
Mechanical Pressure Resistance (Bar): 17 bar (25 °C), 7 bar (95 °C)
Mechanical Pressure Resistance (PSI): 250 psi (77 °F), 100 psi (203 °F)
