Test Frequency: 10Hz-500kHz
Points Of Test Frequency: Continuity
Basic Accuracy: ± 0.08%
AC Drive Level: 10mV to 2Vrms (1m Vrms solution)
DC Drive Level: 0.01V-2V
Output Impedance: 100Ω
Frequency trimming resolution: 5 Digits
Frequency output accuracy: ±0.01%
AC / DC test speed Max.: 8mS
Measured Value Detection Mode: Define upper and lower thresholds according to main and sub parameters
ESR: Series/Parallel
Test Mode: Meter mode/Multi-step mode
Test Range: Automatic/Lock
Indicator: Pass/Fail and Built-in speaker
Safety: EN61010-1
Immunity: EN61326-1
Emissions: EN55022 Class A
Calibration: Open Circuit / Short Circuit: Avoid the misreading caused by the stray capacitance from kelvin clips and fixtures
Auto-save when power-off function: When the power is turned off or encounter a power outage, all the data will be saved automatically and recovered when tester system is switched on again
Power Supply: Voltage 90-132Vac or 198-264Vac (selectable)
Frequency: 47 ~ 63Hz
Display 800*480 Color Screen, 7" TFT
Interface: RS-232, GPIB, Handler, USB
Flash Memory: Built-in flash for storage of 128 groups of Multi-steps setting
Operation: Auto、Manual、RS-232、GPIB、Handler
Temperature : 10°C to 40°C
Humidity : 20 ~ 90%
Dimension (W*H*D): 344x145x343 mm
Weight: 3 Kg
Standard Accessories:Power Cord,User Manual,F423501
Optional Accessories:F423503,F423903,F423905
