HL display range: 170～960HLD
Repeatability: 6HLD
Testing direction: All direction
Optional Impact Device: D, DC, DL, D+15, C, G
Display: 3.9” 240*320(with touch screen), Bright and clear LCD display with backlight
Operating voltage: 3.6V (rechargeable 800 mAh Ni-MH battery)
Charging power supply: DC5V/1A
Printer: Mini thermal printer with RF wireless (Cable no needed)
Operating environment:
- Temperature：-20°C～+50°C
- Humidity: 20%～85%
Storage environment
- Temperature：-30°C～+70°C
- Humidity: 5%～95%
Dimensions: 130mm*86mm*28mm
Weight: 300g (include D type impact device)
Accessories: Display Unit, Impact Device D, Test Block, Mini-printer, Charger, Little Support Ring, Cleaning Brush USB Cable, PC Software CD.
Communication: USB to PC for transfer data
Certificate: CE
Options: Impact Device DC; DL; D+15; C; G
