Capacity: 650N (65KG, 140lbf)
Stroke: 220 mm
Speed:
- Adjustable Range: 30~720 mm/min
- Resolution:0.1 mm/min
- Accuracy: ±1 mm/min
Displacement
- Resolution: 0.01 mm
- Accuracy: ± 0.2mm/min
Operation Mode: Manual, Cycle, Demo, Locating Mode
Protection Functions:
- Position Limit
- Force Limit (connected to force gauge)
- Locked rotor.
- Power Protection
Cycle Program:
- Three-stage cycle
- Displacement-based (D-cycle)
- Force-based(F-cycle)
Outputs:
- USB-B(connect to PC)
- RS232 outputs
- Set point output,
- RS232(connect with force gauge)
Operating Environment: 0 to 40℃,20 to 80% RH
Power Supply: AC100~240V,1A
Dimensions: 630 x 320 x 180 mm
Weight: Approx. 13kg
